Socket: AM4
Graphics: Integrated AMD Radeon™ R Series Graphics in the 7th Generation A-Series APU; Multi-VGA output support : DVI-D/RGB ports : - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz; - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz; Maximum shared memory of 2048 MB.
CPU's supported: AMD AM4 Socket for AMD Ryzen™/7th Generation A-series/Athlon™ Processors ; Supports CPU up to 8 cores; * Refer to www.asus.com for CPU support list
Chipset: AMD B350
Expansion Slots: AMD Ryzen™ Processors: 1 x PCIe 3.0/2.0 x16 (x16 mode) ; AMD 7th Generation A-series/Athlon™ Processors: 1 x PCIe 3.0/2.0 x16 (x8 mode) ; AMD B350 chipset: 2 x PCIe 2.0 x1.
Storage: AMD B350 chipset : 4 x SATA 6Gb/s port(s), gray, Support Raid 0, 1, 10; AMD Ryzen™ Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode); AMD 7th Generation A-series/Athlon™ Processors : 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA mode)
Memory type: AMD Ryzen™ Processors: 2 x DIMM, Max. 32GB, DDR4 3200(O.C.)/2933(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory; AMD 7th Generation A-series/Athlon™ Processors: 2 x DIMM, Max. 32GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory ; Dual Channel Memory Architecture : * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
I/O: 1 x PS/2 keyboard (purple); 1 x PS/2 mouse (green); 1 x DVI-D; 1 x D-Sub; 1 x LAN (RJ45) port(s); 4 x USB 3.1 Gen 1 (blue) ; 2 x USB 2.0 ; 3 x Audio jack(s).
Connectors: 1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin); 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s); 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode); 1 x COM port(s) connector(s); 4 x SATA 6Gb/s connector(s); 1 x CPU Fan connector(s) (1 x 4 -pin); 1 x Chassis Fan connector(s) (1 x 4 -pin); 1 x S/PDIF out header(s); 1 x 24-pin EATX Power connector(s); 1 x 8-pin ATX 12V Power connector(s); 1 x Front panel audio connector(s) (AAFP); 1 x System panel(s) ; 1 x Clear CMOS jumper(s); 1 x Speaker connector.
Audio: Realtek® ALC887 8-Channel High Definition Audio CODEC
LAN: Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
BIOS: 128 Mb Flash ROM, UEFI AMI BIOS, PnP,WfM2.0, SM BIOS 3.0, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, My Favorites, Last Modified log, F12 PrintScreen, ASUS DRAM SPD (Serial Presence Detect) memory information, F6 Qfan Control
Form Factor: mATX Form Factor ; 8.9 inch x 8.7 inch ( 22.6 cm x 22.1 cm ).
OS: Windows® 10 , 64bit
Гаранция: 36 Months
